CityView Architectural Sliding Door

If high performance, strength and functionality is what you are looking for in a commercial sliding door, then you can’t go past the CityView Apartment Sliding Door.





CityView Apartment Door

GREY_CityViewSlidingApmtDoor2Panel_NewBackground

About CityView Architectural Sliding Door

Made with high quality, strong aluminium extrusions, the CityView Architectural Sliding Door allows for extra large door panels szies and accepts a glass thickness of 6mm to 30mm.

Suitable for high end residential and commercial applications, this sliding door system allows you to maximise your views and seamlessly connect indoor spaces with outdoor areas.

Widely used in commercial apartments, the CityView Architectural Sliding Door comes with a range of roller options to accommodate heavy panel weights and ensure smooth and reliable sliding operation for years to come.

The CityView Architectural Sliding Door comes with multiple screening options for internal and external security screens and fly screens and a wide range of architectural lock options to suit your individual preference.

As with all the windows and doors in the CityView range, the Apartment door has been tested and exceeds Australian Standard AS2047.

Window ID	System	Glazing	Cooling Stars	Heating Stars	Cool %	Heat %	Uw	SHGC	Tvw	Air Inf
DAR-001-01	“Cityview” Apartment Door-Single Glazed	6Clr	1	2.5	21%	17%	6.2	0.66	0.7	1.45
DAR-001-02	“Cityview” Apartment Door-Single Glazed	6TS21	3.5	1.5	55%	5%	5.4	0.25	0.16	1.45
DAR-001-03	“Cityview” Apartment Door-Single Glazed	6.38CPNtrl	3	3	49%	28%	4.4	0.41	0.47	1.45
DAR-001-04	“Cityview” Apartment Door-Single Glazed	6.38CPGn	3	3	49%	27%	4.4	0.41	0.56	1.45
DAR-001-05	“Cityview” Apartment Door-Single Glazed	6.38CPGy	3	3	50%	27%	4.4	0.4	0.31	1.45
DAR-001-06	“Cityview” Apartment Door-Single Glazed	6Gy	2	2	37%	8%	6.2	0.46	0.35	1.45
DAR-001-07	“Cityview” Apartment Door-Single Glazed	6EcAdGy	3.5	2.5	54%	21%	4.6	0.33	0.25	1.45
DAR-001-08	“Cityview” Apartment Door-Single Glazed	6SE	3	3	48%	28%	4.5	0.42	0.47	1.45
DAR-001-09	“Cityview” Apartment Door-Single Glazed	6SEGy	4	2.5	57%	20%	4.5	0.29	0.24	1.45
DAR-001-10	“Cityview” Apartment Door-Single Glazed	10.38GyLam	2	2	36%	9%	6.2	0.48	0.33	1.45
DAR-001-11	“Cityview” Apartment Door-Single Glazed	10.38CPClr	2.5	3.5	41%	34%	4.4	0.52	0.63	1.45
DAR-001-12	“Cityview” Apartment Door-Single Glazed	10.38CPGy	3.5	3	51%	26%	4.4	0.38	0.3	1.45
DAR-001-13	“Cityview” Apartment Door-Single Glazed	10.38CPNtl	3	3	49%	28%	4.4	0.41	0.49	1.45
DAR-001-14	“Cityview” Apartment Door-Single Glazed	10.38CPGn	3.5	3	53%	25%	4.4	0.35	0.51	1.45
DAR-001-15	“Cityview” Apartment Door-Single Glazed	6.38CPClr	2.5	3	38%	34%	4.5	0.55	0.65	1.45
DAR-001-16	“Cityview” Apartment Door-Single Glazed	6AzTS21	4	1.5	56%	4%	5.5	0.24	0.12	1.45
DAR-001-17	“Cityview” Apartment Door-Single Glazed	6EVSpGn	3.5	2.5	55%	19%	4.7	0.31	0.39	1.45
DAR-001-18	“Cityview” Apartment Door-Single Glazed	6SpGy	3	0	49%	-2%	6.2	0.29	0.07	1.45
DAR-001-19	“Cityview” Apartment Door-Single Glazed	6EVBGn	3.5		51%	23%	4.6	0.37	0.45	1.45
DAR-001-20	“Cityview” Apartment Door-Single Glazed	6EVAB	4	2.5	56%	18%	4.6	0.3	0.31	1.45
DAR-011-01	"Cityview" Apartment Door - Double Glazed	6Clr/12/6Clr	2.5	4	42%	39%	4	0.54	0.58	1.3
DAR-011-02	"Cityview" Apartment Door - Double Glazed	6Ins/12/6EA	3	4.5	47%	44%	3.5	0.51	0.53	1.3
DAR-011-03	"Cityview" Apartment Door - Double Glazed	6InsEG/12/6Clr	4	3	58%	27%	4	0.31	0.43	1.3
DAR-011-04	"Cityview" Apartment Door - Double Glazed	6InsEG/12/6EA	4.5	3.5	63%	31%	3.5	0.27	0.4	1.3
DAR-011-05	"Cityview" Apartment Door - Double Glazed	6TS21/12/6Clr	5.5	2.5	69%	19%	3.8	0.16	0.12	1.3
DAR-011-06	"Cityview" Apartment Door - Double Glazed	6TS21/12/6EA	5.5	3	73%	21%	3.4	0.14	0.11	1.3
DAR-011-07	"Cityview" Apartment Door - Double Glazed	6LE/12/6Clr	3	4.5	49%	42%	3.5	0.47	0.53	1.3
DAR-011-08	"Cityview" Apartment Door - Double Glazed	6PTech/12/6Clr	5	3.5	65%	31%	3.3	0.25	0.42	1.3
DAR-011-09	"Cityview" Apartment Door - Double Glazed	6PTech/12Ar/6Clr	5	3.5	66%	33%	3.1	0.25	0.42	1.3
DAR-011-10	"Cityview" Apartment Door - Double Glazed	6PTech/12Ar/6ET	5	3.5	67%	33%	3.1	0.24	0.39	1.3
DAR-011-11	"Cityview" Apartment Door - Double Glazed	6PTech/12Ar/6SpGy	5	3.5	68%	32%	3.1	0.23	0.04	1.3
DAR-011-12	"Cityview" Apartment Door - Double Glazed	6Clr/12Ar/10.38ClrLam	2.5	4	44%	40%	3.9	0.52	0.56	1.3
DAR-011-13	"Cityview" Apartment Door - Double Glazed	6SolT/6/6Clr	3.5	3.5	55%	31%	3.9	0.36	0.41	1.3
DAR-011-14	"Cityview" Apartment Door - Double Glazed	6Gy/12Ar/6Gy	4	3.5	58%	28%	3.9	0.31	0.13	1.3
DAR-011-15	"Cityview" Apartment Door - Double Glazed	6Gy/12Ar/6Clr	4	3.5	56%	31%	3.9	0.35	0.27	1.3
DAR-011-16	"Cityview" Apartment Door - Double Glazed	6SpGy/12Ar/6Clr	5	2.5	68%	19%	3.9	0.17	0.06	1.3
DAR-011-17	"Cityview" Apartment Door - Double Glazed	6EoGy/12/6Clr	3.5	3.5	55%	30%	4	0.36	0.29	1.3
DAR-011-18	"Cityview" Apartment Door - Double Glazed	6EuGy/12/6ET	4	3.5	60%	34%	3.5	0.32	0.27	1.3
DAR-011-19	"Cityview" Apartment Door - Double Glazed	6.5FGI Sil/12Ar/6FGI OE Acu	3.5	4.5	55%	43%	3.1	0.42	0.57	1.3
DAR-011-20	"Cityview" Apartment Door - Double Glazed	6.38FGI Ptk Wt /12Ar/6FGI OE Prv	4.5	4	60%	39%	3.1	0.34	0.43	1.3
DAR-011-21	"Cityview" Apartment Door - Double Glazed	6FGI Env Clr / 12Ar / 6FGI OE Clr	3.5	4.5	53%	44%	3.1	0.44	0.57	1.3
DAR-011-22	"Cityview" Apartment Door - Double Glazed	6FGI Env Gy / 12Ar / 6FGI OE Gy	5	3.5	65%	34%	3.1	0.26	0.27	1.3

WERS Ratings

The Window Energy Rating Scheme (WERS) is accredited by the AFRC – which means that WERS ratings are compliant with the NCC.

Reports are prescribed both the window performance for total window U Value (Uw) and total window Solar Heat Gain Coefficient (SHGCw).

U-value

U-value measures how well a product prevents heat from escaping.

It is a measure of the rate of non-solar heat loss or gain through a material or assembly.

U-value ratings generally fall between 2.0-10.0 W/m2.K for Australian products. The lower the U-value, the greater a window’s resistance to heat and cold flow and the better its insulating value.

Solar Heat Gain Co-efficient (SHGC)

SHGC measures how well a product blocks heat caused by sunlight. SHGC is expressed as a number between 0 and 1. The lower a window’s SHGC, the less solar heat it transmits.

Access Via Darley Portal

image presents CityView ArchSDoor LandscapeFlyer_2Sep22-COVER

Download Product Flyer

Download CityView™ Brochure

Design Features

Accepts glass thickness from 6mm to 30mm
Compatible with other Darley Aluminium Commercial and Residential Systems
Compatible with various Darley Mainframe Options
Multiple screening options available for internal or external screening

Custom made anti-lift and filler blocks for quick installation
Range of roller options to accommodate heavy panel weights
Pre-punched sill requires no additional fabrication

Tested and Approved by an independent NATA accredited laboratory
Maximum recommended panel size of 2700mm x 1500mm
Maximum recommended panel weight of 200kg (dependent on rollers and operational force)

Specifications

System	Maximum weight per panel	Maximum hieight	Maxiumim Width	Glass Thickness	Test Report No.	Water Rating (Pa)	Structural (Pa)	Ultimate (Pa)
Architectural Slider	200kg	3200mm	1500mm	6mm – 30mm	AZT0144.22	450	1,600	2,800
Architectural Slider (Flush Sill)	200kg	3200mm	1500mm	6mm – 30mm	KSTL025	300	1,800	4,500
Architectural Stacker	200kg	3200mm	1500mm	6mm – 30mm	AZT0137.17	420	1,487	2,300
HD High Sill Architectural Slider	200kg	3200mm	1500mm	6mm – 30mm	AZT0060.13	700	1,890	2,700
HD High Sill Architectural Stacker	200kg	3200mm	1500mm	6mm – 30mm	AZT0095.13	600	1890	2700
