CityView High Performance Awning & Casement Window

The CityView High Performance Awning & Casement Window features extra-strong aluminium frames for increased strength and performance and to accommodate larger glass panels.



About CityView High Performance Awning & Casement Window

An ideal choice for high wind load areas such as commercial apartments, the Heay Duty Awning window also offers protection against extreme weather conditions and comes with a range of heavy duty mullions.

This high-performance awning window uses the same sash for both awning and casement windows and also features a self-draining transom. It also come with a wide range of stay options and cam locks to suit any application.

Compatible with Darley’s other residential and commercial window and door systems, the CityView heavy duty awning window accepts a glass thickness of 6mm to 30mm.

Designed and engineered for the harsh Australian climatic conditions, the CityView Heavy Duty Awning Window has been tested and accepts Australian Standard AS2047.

Window ID	System	Glazing	Cooling Stars	Heating Stars	Cool %	Heat %	Uw	SHGC	Tvw	Air Inf
DAR-006-01	“Cityview” Awning Window-Single Glazed	6Clr	1.5	3	28%	21%	6.9	0.53	0.52	0.25
DAR-006-02	“Cityview” Awning Window-Single Glazed	6Gry	2.5	2.5	39%	14%	6.9	0.39	0.26	0.25
DAR-006-03	“Cityview” Awning Window-Single Glazed	6TS21	3.5	2.5	52%	11%	6.4	0.23	0.12	0.25
DAR-006-04	“Cityview” Awning Window-Single Glazed	6.38CPNtl	3	3.5	47%	28%	5.8	0.35	0.35	0.25
DAR-006-05	“Cityview” Awning Window-Single Glazed	6.38CPGrn	3	3.5	47%	28%	5.8	0.35	0.42	0.25
DAR-006-06	“Cityview” Awning Window-Single Glazed	6.38CPGry	3	3.5	47%	27%	5.8	0.34	0.23	0.25
DAR-006-07	“Cityview” Awning Window-Single Glazed	6.38CPClr	2.5	4	40%	34%	5.7	0.45	0.49	0.25
DAR-006-08	“Cityview” Awning Window-Single Glazed	6.38ClrLam	1.5	3	30%	22%	6.8	0.51	0.52	0.25
DAR-006-09	“Cityview” Awning Window-Single Glazed	6AzTS21	3.5	2.5	52%	12%	6.4	0.22	0.09	0.25
DAR-006-10	“Cityview” Awning Window-Single Glazed	6EVGy	3	3	50%	24%	5.8	0.3	0.19	0.25
DAR-006-11	“Cityview” Awning Window-Single Glazed	6EVClr	2.5	3.5	41%	31%	5.8	0.42	0.4	0.25
DAR-006-12	“Cityview” Awning Window-Single Glazed	6SpGy	3	2	48%	8%	6.8	0.26	0.05	0.25
DAR-006-13	“Cityview” Awning Window-Single Glazed	6AB	2.5	2.5	41%	14%	6.8	0.36	0.31	0.25
DAR-006-14	“Cityview” Awning Window-Single Glazed	6EVBz	3	3	48%	25%	5.8	0.32	0.22	0.25
DAR-006-15	“Cityview” Awning Window-Single Glazed	6SpGn	2.5	2.5	41%	14%	6.8	0.36	0.4	0.25
DAR-006-16	“Cityview” Awning Window-Single Glazed	6EVBGn	3	3	48%	25%	5.8	0.32	0.34	0.25
DAR-006-17	“Cityview” Awning Window-Single Glazed	6EVAB	3.5	3	52%	22%	5.8	0.27	0.23	0.25
DAR-006-18	“Cityview” Awning Window-Single Glazed	6EVSpGn	3.5	3	51%	22%	5.8	0.27	0.29	0.25
DAR-016-01	"Cityview" Awning Window - Double Glazed	6Clr/12/6Clr	2.5	4.5	44%	47%	4.8	0.47	0.47	0.25
DAR-016-02	"Cityview" Awning Window - Double Glazed	6LE/12/6Clr	3	5	50%	50%	4.3	0.41	0.44	0.25
DAR-016-03	"Cityview" Awning Window - Double Glazed	6InsClr/12/6EA	3	5	48%	51%	4.3	0.44	0.44	0.25
DAR-016-04	"Cityview" Awning Window - Double Glazed	6InsEG/12/6Clr	4	4	57%	36%	4.8	0.28	0.35	0.25
DAR-016-05	"Cityview" Awning Window - Double Glazed	6InsEG/12/6EA	4.5	4	61%	40%	4.3	0.25	0.32	0.25
DAR-016-06	"Cityview" Awning Window - Double Glazed	6InsTS21/12/6Clr	5	3.5	66%	30%	4.6	0.16	0.1	0.25
DAR-016-07	"Cityview" Awning Window - Double Glazed	6TS21/12/6EA	5	3.5	69%	32%	4.3	0.14	0.09	0.25
DAR-016-08	"Cityview" Awning Window - Double Glazed	6GyLE/12Ar/6.38ClrLam	4.5	4	64%	39%	4.1	0.21	0.18	0.25
DAR-016-09	"Cityview" Awning Window - Double Glazed	6/12/6EVClr	3.5	5	50%	48%	4.4	0.4	0.37	0.25
DAR-016-10	"Cityview" Awning Window - Double Glazed	6EVClr/12/6Clr	3.5	4.5	52%	47%	4.4	0.38	0.37	0.25
DAR-016-11	"Cityview" Awning Window - Double Glazed	6TS21/12/6EVClr	5	3.5	67%	33%	4.4	0.15	0.09	0.25
DAR-016-12	"Cityview" Awning Window - Double Glazed	6SpGn/12/6EVClr	4.5	4	61%	38%	4.4	0.23	0.28	0.25
DAR-016-13	"Cityview" Awning Window - Double Glazed	6SpGn/12/6Clr	4	4	56%	37%	4.8	0.28	0.35	0.25
DAR-016-14	"Cityview" Awning Window - Double Glazed	6TS21Gn/12/6Clr	5	3.5	65%	30%	4.6	0.16	0.1	0.25
DAR-016-15	"Cityview" Awning Window - Double Glazed	6.38ClrLam/12/6.38ClrLam	3	4.5	46%	46%	4.7	0.44	0.46	0.25
DAR-016-16	"Cityview" Awning Window - Double Glazed	6.38GyLam/12Ar/6.38ClrLam	3.5	4.5	53%	41%	4.7	0.33	0.22	0.25
DAR-016-17	"Cityview" Awning Window - Double Glazed	6EVClr/6Ar/6Clr	3.5	4.5	51%	45%	4.6	0.38	0.37	0.25
DAR-016-18	"Cityview" Awning Window - Double Glazed	6SpGy/6Ar/6Clr	4.5	3.5	63%	28%	4.9	0.18	0.05	0.25
DAR-016-19	"Cityview" Awning Window - Double Glazed	6/12Ar/10.38ClrLam	3.5	5	45%	48%	4.6	0.45	0.46	0.25
DAR-016-20	"Cityview" Awning Window - Double Glazed	6Gy/12Ar/6Gy	4	4	56%	38%	4.7	0.29	0.11	0.25
DAR-016-21	"Cityview" Awning Window - Double Glazed	6Gy/12Ar/6Clr	3.5	4	55%	40%	4.7	0.31	0.22	0.25
DAR-016-22	"Cityview" Awning Window - Double Glazed	6SpGy/12Ar/6Clr	4.5	3.5	64%	30%	4.7	0.17	0.05	0.25
DAR-016-23	"Cityview" Awning Window - Double Glazed	6.5FGI Sil/12Ar/6FGI OE Acu	3.5	5	54%	51%	4	0.37	0.47	0.25
DAR-016-24	"Cityview" Awning Window - Double Glazed	6.38FGI Ptk Wt /12Ar/6FGI OE Prv	4	4.5	58%	47%	4	0.31	0.35	0.25
DAR-016-25	"Cityview" Awning Window - Double Glazed	6FGI Env Clr / 12Ar / 6FGI OE Clr	3.5	5	53%	52%	4	0.39	0.47	0.25
DAR-016-26	"Cityview" Awning Window - Double Glazed	6FGI Env Gy / 12Ar / 6FGI OE Gy	4.5	4.5	62%	43%	4	0.24	0.22	0.25

WERS Ratings

The Window Energy Rating Scheme (WERS) is accredited by the AFRC – which means that WERS ratings are compliant with the NCC.

Reports are prescribed both the window performance for total window U Value (Uw) and total window Solar Heat Gain Coefficient (SHGCw).

U-value

U-value measures how well a product prevents heat from escaping.

It is a measure of the rate of non-solar heat loss or gain through a material or assembly.

U-value ratings generally fall between 2.0-10.0 W/m2.K for Australian products. The lower the U-value, the greater a window’s resistance to heat and cold flow and the better its insulating value.

Solar Heat Gain Co-efficient (SHGC)

SHGC measures how well a product blocks heat caused by sunlight. SHGC is expressed as a number between 0 and 1. The lower a window’s SHGC, the less solar heat it transmits.

Access Via Darley Portal

Download Product Flyer

Download CityView™ Brochure

Design Features

Accepts glass thickness from 6mm – 20mm
Compatible with Darley’s other commercial and residential window & door systems

Accepts a variety of awning sash options (refer to Awning Section)
Range of heavy duty mullion options available for tall framing and high wind areas

Specifications

System	Maximum weight per sash	Maximum Sash Height	Maximum Sash Width	Glass Thickness	Test Report No.	Water Rating PA	Structural PA	Ultimate PA
